Parameter Condition Specification
Low pass filter order - N/A - 2
Insertion loss - 1 KHz - Max. 1dB
Insertion loss distortion - 0,2 KHz to 4 KHz - Max. 1dB
Attenuation in stop band - 32 KHz - Min. 20 dB
Attenuation in stop band - 100 KHz to 1104 KHz - Min.40 dB
Delay distortion - 0,2 KHz to 4 KHz - Max. 200 ms
Return loss - 0,2 KHz to 3,4 KHz - Min. 10 dB
Return loss - 3,4 KHz to 4 KHz - Min. 8 dB
Longitudinal balance (LCL) - 0,05 KHz to 3,4 KHz - Min. 46 dB
Longitudinal balance (LCL) - 3,4 KHz to 4 KHz - Min.40 dB
Isolation resistance (A-B) - 100V - Min. 1 G Ohm
Isolation resistance (GND) - 100V - Min. 10 G Ohm
DC resistance - Output Shorted - Max. 90 Ohm
