CARATTERISTICHE HARDWARE
Processore: Qualcomm 560MHz CPU, MIPS 74Kc
Memoria: 64MB DDR2 RAM,8MB Flash
Interfaccia:
- 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
- 1 Reset Button
Alimentazione:
- Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
- Voltage range: 16-27VDC
Dimensioni ( L x P x A ): 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
Guadagno antenna: 23dBi
Ampiezza del diagramma di emissione: 7°(Azimuth), 10°(Elevation)
Sicurezza:
- 15KV ESD Protection
- 6KV Lightning Protection
Enclosure:
- Material: Outdoor PC stabilized plastic
- Weatherproof: IP65 water and dust proof design

CARATTERISTICHE WIRELESS
Standard wireless: IEEE 802.11a/n
Protocollo proprietario: TDMA Mode (with Pharos MAXtream enabled)
Velocità wireless:
- Up to 150Mbps (40MHz,Dynamic)
- Up to 72.2Mbps (20MHz,Dynamic)
- Up to 36.1Mbps (10MHz,Dynamic)
- Up to 18.05Mbps (5MHz,Dynamic)
Frequenza: 5.15~5.85GHz
Potenza di trasmissione: Max. 23dBm (Adjustable power by 1dBm)

CARATTERISTICHE SOFTWARE
IPv6: Yes
Configurazione di rete:
- WAN: Static/Dynamic/PPPoE/L2TP/PPTP
- LAN: Static/Dynamic/DHCP
- Forwarding: ALG/UPnP/Virtual Server/Port Trigger
- Security: SPI Firewall/ Ping Forbidden/DoS Protection
- Access Control
- Static Routing
- Bandwidth Control
- IP & MAC Binding
Configurazioni wireless:
- Pharos MAXtream TDMA Technology
- Selectable Channel Width: 5/10/20/40MHz
- Auto Channel Selection
- Transmit Power Control
- Dynamic Frequency Selection(DFS)
- WDS Enable/Disable
- Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
- 64/128/152-bit WEP Encryption
- SSID Broadcast Enable/Disable
- Multi-SSID with VLAN Tagging(AP Mode only)
- Distance/ACK Timeout Setting
- Wireless MAC Address Filter
- Wireless Advanced:
- Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
- Long Range PtP
Gestione:
- Discovery and Remote Management via Pharos Control application
- HTTP/HTTPS Web-based management
- System log
- SNMP Agent(v2c)
- Ping Watch Dog
- Dynamic DDNS
- SSH Server
Tool di sistema:
- Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
- Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
- Spectrum Analyzer
- Speed Test
- Ping
- Traceroute
- Antenna Alignment
Ottimizzazioni di sistema: Optimized IGMP Snooping/Proxy for multicast applications

ALTRO
Certificazione: CE, FCC, RoHS, IP65
Contenuto della confezione:
- Outdoor Wireless CPE
- 24V 0.25A Passive PoE Adapter
- Pole Mounting Kits
- AC Power Cord
- Installation Guide
Requisiti di sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Ambiente:
- Operating Temperature: -40℃~70℃ (-40℉~158℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~95% non-condensing
