Standards and Protocols: IEEE802.3, 802.3u, 802.3ab, 802.3x, CSMA/CD, TCP/IP
Basic Function: Wire-speed Performance, MAC Address Auto-Learning and Auto-aging, IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode
Backbound Bandwidth: 16Gbps
MAC Address Table: 4k
Forwarding Rate: 10BASE-T: 14880pps/port, 100BASE-TX: 148800pps/port, 1000BASE-T: 1488000pps/port
Transmission Method: Store-and-Forward
Ports: 8 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
Network Media: 10Base-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ù STP (maximum 100m), 100Base-Tx: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ù STP (maximum 100m), 1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED Indicators: Power, 10/100M, 1000M
Safety & Emission: FCC, CE
Dimensions (W*D*H): 7.9*5.5*1.1 in. (200*140*28 mm)
Environment: Operating Temperature: 0‚~40‚ (32‚~104‚), Storage Temperature: -40‚~70‚ (-40‚~158‚), Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing
Power: External Power Adapter
